060-113366 | DANFOSS KP35 Pressure Switch Setting Range 0.2 to 7.5

Brand: Danfoss

Color: White

Features:

• Features: Wide setting range | Shock and impact resistant | Snap action electrical contacts minimize chatter, bounce, and wear, and ensure long term electrical and mechanical reliability
• Suitable for alternating current and direct current | Can be used for both liquids and gases (KPI) | Single pressure switches and thermostats are fitted with a single pole double throw contact system (SPDT)
• Ambient Temperature Range: -40°C to 65°C | Differential Pressure switch Range: 0.7 Bar to 4 Bar | Regulation Range: -0.2 Bar to 7.5 Bar | Max. Working Pressure: 17 bar | Max. test pressure: 22 bar
• Pressure range category: Low pressure | Pressure Connections Size: 1/4" | Standard: ISO 228-1, Connection Type: G | Enclosure rating IP: 30 | Electrical Connection: Rubber cable gland | Electrical connection size: 6-14 mm
• Approval: CE-marked in accordance with LVD 2014/35/EU: EN 60947-1, EN 60947-4-1, EN 60947-5-1 Underwriters Laboratories Inc., UL.Supply Scope: 1 unit of Danfoss KP 35 Pressure Switch and Instruction Manual | Applications: Water Pump Control, Steam Boilers, Industry Applications, Refrigeration Compressors, Air Conditioning Systems, Heavy Engineering, Turbines, Industries, HVAC

model number: 060-113366

Part Number: 060-113366

Details: PRESSURE SWITCH, TYPE: KP35, RESET FUNCTION: AUTO, CONTACT FUNCTION: SPDT, REGULATION RANGE: 6 INHG - 108 PSIG, PRESSURE CONNECTION SIZE: 1/4, PRESSURE CONNECTION TYPE: G, PRESSURE MALE/FEMALE: MALE

Package Dimensions: 5.1 x 3.6 x 1.7 inches
